Schema Evolution

Schema evolutions are a feature you can use to update your whole Data Flow to reflect edits to a collection, preventing your Data Flow from failing due to mismatched components.

info

Evolutions are a relatively advanced concept in Estuary. Before continuing, you should have a basic understanding of Estuary's captures, collections, schemas, and materializations.

Introduction

Estuary stores your real-time datasets as collections, groups of continually updating JSON documents. Captures write data to collections, and materializations read data from collections. Together, these three components form a complete Data Flow.

Note

Derivations can also read data from and write data to collections. To keep things simple in this article, we'll be referring only to captures and materializations.

graph LR; Source[Source System]-->Capture; Capture-->Collection; Collection-->Materialization; Materialization-->Dest[Destination System];

Each collection and its data are defined by a collection specification, or spec. The spec serves as a formal contract between the capture and the materialization, ensuring that data is correctly shaped and moves through the Data Flow without error.

The spec includes the collection's key, its schema, and logical partitions of the collection, if any. Any of these parts may change:

• When a collection key changes, you can separately manage materialization group-by keys during field selection.
• Estuary's schema evolution feature automatically picks up new fields and widens data types.
• Changes to logical partitions will require a corresponding dataflow reset to reset the collection schema.

Collection specs may change for a variety of reasons, such as:

• The source system is a database, and someone ran an ALTER TABLE statement on a captured table, so you need to update the collection schema (through AutoDiscover or manually).
• The source system contains unstructured data, and some data with a different shape was just captured so you need to update the collection schema (through AutoDiscover or manually).
• Someone manually changed the collection's logical partitions.

Regardless of why or how a spec change is introduced, the effect is the same. Estuary will never permit you to publish changes that break this contract between captures and materializations, so you'll need to update the contract.

What do schema evolutions do?

The schema evolution feature is available in the Estuary web app when you're editing pre-existing entities. It notices when one of your edits would cause other components of the Data Flow to fail, alerts you, and gives you the option to automatically update the specs of these components to prevent failure.

In other words, evolutions happen in the draft state. Whenever you edit, you create a draft. Evolutions add to the draft so that when it is published and updates the active data flow, operations can continue seamlessly.

Alternatively, you could manually update all the specs to agree to your edit, but this becomes time-consuming and repetitive.

Evolutions can prevent errors resulting from mismatched specs in two ways:

• Materialize data to a new resource in the endpoint system: The evolution updates the affected materialization bindings to increment their backfill counter, which causes the materialization to refresh the resource (database table, for example) and backfill it from the beginning. If the schema change requires a different table structure (such as an incompatible column type change or a primary key change), the resource is dropped and recreated; otherwise it is truncated, preserving table-level metadata such as partitioning and clustering.

  This is a simpler change, and how evolutions work in most cases.

• Reset the collection: The evolution uses a dataflow reset to reset the collection. The re-created collection starts out empty and backfills from the source. The reset also updates all captures and materializations that reference the collection to increment their backfill counters.

  This is a more complicated change, and evolutions only work this way when necessary: when the collection key or logical partitioning changes.

In either case, the names of the destination resources will remain the same. For example, a materialization to Postgres refreshes the affected tables with the same names they had previously — typically by truncating, or by dropping and recreating when the schema change requires a different table structure.

Also in either case, only the specific bindings that had incompatible changes will be affected. Other bindings will remain untouched, and will not re-backfill.

The onIncompatibleSchemaChange field in materialization specs provides granular control over responses to incompatible schema changes. This field can be set at the top level of a materialization spec or within each binding. If not specified at the binding level, the top-level setting applies by default. The onIncompatibleSchemaChange field offers four options:

• backfill (default if unspecified): Increments the backfill counter for affected bindings, refreshing the destination resources (truncating, or dropping and recreating when the schema change requires it) and backfilling them.
• disableBinding: Disables the affected bindings, requiring manual intervention to re-enable and resolve the incompatible fields.
• disableTask: Disables the entire materialization, necessitating human action to re-enable and address the incompatible fields.
• abort: Halts any automated action, leaving the resolution decision to a human.

These behaviors are triggered only when an automated action detects an incompatible schema change. Manual changes via the UI will ignore onIncompatibleSchemaChange. This feature can be configured using flowctl or the "Advanced specification editor".
