Prefix-based access control
Estuary's authorization model is built around prefixes. By default, your organization gets a single top-level prefix (e.g. acmeCo/) and all users and tasks operate within it with broad access. For organizations that need stronger isolation — between environments, regions, or teams — you can configure access at sub-prefix granularity.
This guide explains the four layers that control access, and walks through three common configurations.
The four layers
Full isolation between sub-prefixes requires configuring all four layers:
| Layer | What it controls | Configured via |
|---|---|---|
| User grants | Which prefixes a user can create, modify, or view tasks in | Web app (Admin > Access Grants > Organization Membership) or CLI |
| Role grants | Which collections a task can read from or write to | Web app (Admin > Access Grants > Data Sharing) or CLI |
| Storage mappings | Where collection data is physically stored | Web app (Admin > Storage Mappings) |
| Data plane access | Which data planes tasks can run on | Estuary support (no self-service UI) |
A note on grants
User and role grants are additive — a more specific grant cannot restrict a broader one. If acmeCo/ has write access to acmeCo/, then a user or task in acmeCo/staging/ inherits that access regardless of what grants you add at the sub-prefix level. To restrict access, you must delete the broader grant and replace it with narrower ones.
Storage mappings and data plane access work differently — they use longest-prefix-match, so sub-prefix entries do take precedence over parent entries for those layers.
Scenario 1: Default (single prefix)
Every new organization starts with this setup. All users and tasks share a single prefix with no isolation.
| Layer | Behaviour | Default configuration |
|---|---|---|
| User grants | All users can create and modify tasks anywhere in the prefix | Users are granted admin to acmeCo/ |
| Role grants | All tasks can read and write any collection in the prefix | acmeCo/ → acmeCo/ (write)acmeCo/ → ops/acmeCo/ (read, for task logs) |
| Storage mappings | All collections stored in the same location | Single mapping at acmeCo/ |
| Data plane access | All tasks run on the same data plane | Single data plane at acmeCo/ |
This works well for small teams where isolation is not needed.
Scenario 2: Environment isolation with cross-read access
Two sub-prefixes — acmeCo/dev/ and acmeCo/prod/ — where dev tasks can read from prod collections (e.g. for testing pipelines against real data), but dev users cannot create or modify prod tasks.
| Layer | Behaviour | Configuration |
|---|---|---|
| User grants | Dev users can only create or modify tasks in acmeCo/dev/; prod users are scoped to acmeCo/prod/ | Dev team: admin to acmeCo/dev/Prod team: admin to acmeCo/prod/ |
| Role grants | Dev tasks can read prod collections but cannot write to them; prod tasks are fully isolated from dev | Delete acmeCo/ → acmeCo/ (write)Add acmeCo/dev/ → acmeCo/dev/ (write)Add acmeCo/dev/ → acmeCo/prod/ (read)Add acmeCo/prod/ → acmeCo/prod/ (write) |
| Storage mappings | Dev and prod collection data is stored separately | Create mappings for acmeCo/dev/ and acmeCo/prod/; parent mapping can be kept as fallback or removed |
| Data plane access | Both environments share the same compute resources | No changes needed if sharing a single data plane — tasks inherit via longest-prefix-match |
Scenario 3: Full isolation between sub-prefixes
Two completely separate sub-prefixes — acmeCo/EU/ and acmeCo/US/ — with separate storage and data planes. User A can administer both; User B can only administer acmeCo/US/.
| Layer | Behaviour | Configuration |
|---|---|---|
| User grants | User A can administer both regions; User B can only administer US | User A: admin to acmeCo/EU/ and acmeCo/US/User B: admin to acmeCo/US/ only |
| Role grants | EU and US tasks cannot access each other's collections | Delete acmeCo/ → acmeCo/ (write)Add acmeCo/EU/ → acmeCo/EU/ (write)Add acmeCo/US/ → acmeCo/US/ (write) |
| Storage mappings | Collection data is physically separated by region | Create acmeCo/EU/ → EU bucketCreate acmeCo/US/ → US bucketRemove parent acmeCo/ mapping to prevent cross-region fallback |
| Data plane access | Tasks run on region-specific compute | Contact Estuary support to create per-sub-prefix data plane grants and remove the parent acmeCo/ data plane grant |
Data plane visibility for sub-prefix-only users is currently limited in some parts of the UI due to an ongoing migration. If a sub-prefix user cannot see their assigned data plane, contact Estuary support to verify the grant is in place.
Limitations
- Private links cannot be restricted to sub-prefixes. Preventing
acmeCo/prod/andacmeCo/dev/tasks from connecting to the same private database requires separate data planes — there is no per-prefix private link scoping. - Data plane grants have no self-service UI — contact Estuary support to configure them.
